Unit 7 Test Study Guide: Polygons and Quadrilaterals

Geometry unlocks a fascinating world of shapes, angles, and spatial relationships. Unit 7 delves into the properties of polygons and quadrilaterals, building a foundational understanding for more advanced geometric concepts. Mastering this material requires a comprehensive grasp of definitions, theorems, and problem-solving techniques related to these shapes. This study guide aims to provide you with the necessary tools to excel in your Unit 7 test.

Polygons: A General Overview

A polygon is a closed two-dimensional figure formed by three or more straight line segments called sides. These sides meet at points called vertices. Polygons are fundamental building blocks in geometry, and understanding their properties is essential.

Key Definitions and Classifications

• Convex Polygon: A polygon where all interior angles are less than 180 degrees. In other words, any line segment connecting two points inside the polygon lies entirely within the polygon.

• Concave Polygon: A polygon with at least one interior angle greater than 180 degrees. This means that at least one line segment connecting two points inside the polygon will pass outside the polygon.

• Regular Polygon: A polygon that is both equilateral (all sides are congruent) and equiangular (all angles are congruent).

• Irregular Polygon: A polygon that is not regular, meaning it is either not equilateral or not equiangular, or neither.

• N-gon: A polygon with n sides. Common polygons have specific names:

  • Triangle: 3 sides
  • Quadrilateral: 4 sides
  • Pentagon: 5 sides
  • Hexagon: 6 sides
  • Heptagon (or Septagon): 7 sides
  • Octagon: 8 sides
  • Nonagon: 9 sides
  • Decagon: 10 sides
  • Hendecagon (or Undecagon): 11 sides
  • Dodecagon: 12 sides

Angle Sum Theorems

Understanding the relationships between the number of sides of a polygon and the sum of its interior angles is crucial.

• Interior Angle Sum Theorem: The sum of the interior angles of a convex n-gon is given by the formula:

  (n - 2) * 180°

  This theorem allows you to calculate the total degrees in any polygon, regardless of the number of sides.

• Exterior Angle Sum Theorem: The sum of the exterior angles of any convex polygon (one exterior angle at each vertex) is always 360°. This holds true regardless of the number of sides the polygon has.

• Individual Interior Angle of a Regular Polygon: If a polygon is regular, you can find the measure of each interior angle by dividing the total interior angle sum by the number of sides:

  [(n - 2) * 180°] / n

• Individual Exterior Angle of a Regular Polygon: Similarly, for a regular polygon, each exterior angle measures:

  360° / n

Applying Polygon Properties: Example Problems

Let's apply these concepts to some example problems:

Example 1: Find the sum of the interior angles of a hexagon.

• A hexagon has 6 sides (n = 6).
• Using the Interior Angle Sum Theorem: (6 - 2) * 180° = 4 * 180° = 720°
• Therefore, the sum of the interior angles of a hexagon is 720°.

Example 2: Find the measure of each interior angle of a regular octagon.

• An octagon has 8 sides (n = 8).
• First, find the total interior angle sum: (8 - 2) * 180° = 6 * 180° = 1080°
• Since it's a regular octagon, divide the sum by the number of sides: 1080° / 8 = 135°
• Each interior angle of a regular octagon measures 135°.

Example 3: Each interior angle of a regular polygon measures 160°. How many sides does the polygon have?

• Let n be the number of sides.
• We know [(n - 2) * 180°] / n = 160°
• Multiply both sides by n: (n - 2) * 180° = 160n
• Expand: 180n - 360 = 160n
• Subtract 160n from both sides: 20n - 360 = 0
• Add 360 to both sides: 20n = 360
• Divide by 20: n = 18
• The polygon has 18 sides (an 18-gon).

Quadrilaterals: Diving Deeper into Four-Sided Figures

A quadrilateral is a polygon with four sides. However, the world of quadrilaterals is much more diverse than just "four-sided figures." Understanding the specific properties and relationships between different types of quadrilaterals is critical.

The Quadrilateral Hierarchy

Quadrilaterals can be organized into a hierarchy based on their properties. This hierarchy helps visualize the relationships between different shapes.

• Quadrilateral: The most general category – any four-sided polygon.

• Trapezoid: A quadrilateral with at least one pair of parallel sides. These parallel sides are called bases.

  • Isosceles Trapezoid: A trapezoid where the non-parallel sides (legs) are congruent. Isosceles trapezoids also have congruent base angles.

• Parallelogram: A quadrilateral with two pairs of parallel sides. Parallelograms possess many important properties:

  • Opposite sides are congruent.
  • Opposite angles are congruent.
  • Consecutive angles are supplementary (add up to 180°).
  • Diagonals bisect each other.

• Rectangle: A parallelogram with four right angles. Rectangles inherit all properties of parallelograms, plus:

  • All angles are 90°.
  • Diagonals are congruent.

• Rhombus: A parallelogram with four congruent sides. Rhombi also inherit all parallelogram properties, plus:

  • All sides are congruent.
  • Diagonals are perpendicular.
  • Diagonals bisect the angles.

• Square: A parallelogram with four right angles and four congruent sides. A square is both a rectangle and a rhombus, so it possesses all properties of both.

• Kite: A quadrilateral with two pairs of adjacent sides that are congruent, but opposite sides are not congruent.

  • Diagonals are perpendicular.
  • One pair of opposite angles are congruent (the angles between the non-congruent sides).
  • One diagonal bisects the other diagonal.

Important Relationships:

• A square is always a rectangle, rhombus, and parallelogram.
• A rectangle is always a parallelogram.
• A rhombus is always a parallelogram.
• A parallelogram is always a quadrilateral.
• An isosceles trapezoid is always a trapezoid.

Key Properties Summarized

Solving Problems with Quadrilateral Properties

Applying these properties is key to solving geometry problems. Here are some examples:

Example 1: In parallelogram ABCD, angle A measures 60°. Find the measure of angle B.

• In a parallelogram, consecutive angles are supplementary.
• Therefore, angle A + angle B = 180°
• 60° + angle B = 180°
• Angle B = 120°

Example 2: ABCD is a rectangle. AC = 10. Find BD.

• In a rectangle, diagonals are congruent.
• Therefore, BD = AC = 10.

Example 3: PQRS is a rhombus. Angle PQR = 110°. Find angle PQS.

• In a rhombus, diagonals bisect the angles.
• Therefore, angle PQS = 1/2 * angle PQR = 1/2 * 110° = 55°

Example 4: In kite WXYZ, angle WXY = 120° and angle WZY = 80°. Find angle XWZ.

• In a kite, one pair of opposite angles are congruent. Since the adjacent sides to angles WXY and WZY are not congruent, then those angles are not congruent. Therefore, the congruent angles must be XWZ and XYZ.
• The sum of the interior angles of a quadrilateral is 360°.
• angle WXY + angle XYZ + angle WZY + angle XWZ = 360°
• 120° + angle XYZ + 80° + angle XWZ = 360°
• Since angle XYZ = angle XWZ, we can substitute:
• 120° + angle XWZ + 80° + angle XWZ = 360°
• 200° + 2 * angle XWZ = 360°
• 2 * angle XWZ = 160°
• angle XWZ = 80°

Example 5: ABCD is an isosceles trapezoid with bases AB and CD. If angle A = 50°, find angle D.

• In an isosceles trapezoid, base angles are congruent. Therefore, angle A is congruent to angle B, and angle C is congruent to angle D. Also, consecutive angles between the bases are supplementary.
• Therefore, angle A + angle D = 180°
• 50° + angle D = 180°
• angle D = 130°

Coordinate Geometry and Quadrilaterals

Coordinate geometry provides a powerful way to prove properties of quadrilaterals using algebraic methods. By plotting points on a coordinate plane and using formulas for distance, slope, and midpoint, you can determine if a quadrilateral is a parallelogram, rectangle, rhombus, square, or trapezoid.

Key Formulas and Concepts

• Distance Formula: Used to calculate the length of a line segment between two points (x1, y1) and (x2, y2):

  √((x2 - x1)² + (y2 - y1)²)

• Slope Formula: Used to determine the slope of a line passing through two points (x1, y1) and (x2, y2):

  (y2 - y1) / (x2 - x1)

• Midpoint Formula: Used to find the midpoint of a line segment between two points (x1, y1) and (x2, y2):

  ((x1 + x2)/2, (y1 + y2)/2)

Using Coordinate Geometry to Prove Quadrilateral Properties

1. Parallelogram:

   • Prove that opposite sides have equal length using the distance formula.
   • Prove that opposite sides have equal slopes (are parallel).
   • Prove that the diagonals bisect each other by showing that they have the same midpoint.

2. Rectangle:

   • Prove that it is a parallelogram.
   • Prove that adjacent sides are perpendicular by showing that their slopes are negative reciprocals of each other (their product is -1).
   • Prove that the diagonals are congruent using the distance formula.

3. Rhombus:

   • Prove that it is a parallelogram.
   • Prove that all four sides are congruent using the distance formula.
   • Prove that the diagonals are perpendicular by showing that their slopes are negative reciprocals of each other.

4. Square:

   • Prove that it is both a rectangle and a rhombus.

5. Trapezoid:

   • Prove that at least one pair of sides are parallel by showing that they have equal slopes.

6. Isosceles Trapezoid:

   • Prove that it is a trapezoid.
   • Prove that the non-parallel sides (legs) are congruent using the distance formula.

7. Kite:

   • Prove that two pairs of adjacent sides are congruent using the distance formula. Make sure the opposite sides are not congruent.

Example Problems in Coordinate Geometry

Example: The vertices of quadrilateral ABCD are A(-2, 2), B(2, 4), C(4, 0), and D(0, -2). Determine whether ABCD is a parallelogram.

• Step 1: Find the slopes of the sides.

  • Slope of AB = (4 - 2) / (2 - (-2)) = 2 / 4 = 1/2
  • Slope of BC = (0 - 4) / (4 - 2) = -4 / 2 = -2
  • Slope of CD = (-2 - 0) / (0 - 4) = -2 / -4 = 1/2
  • Slope of DA = (2 - (-2)) / (-2 - 0) = 4 / -2 = -2

• Step 2: Analyze the slopes.

  • AB and CD have the same slope (1/2), so they are parallel.
  • BC and DA have the same slope (-2), so they are parallel.

• Step 3: Conclusion.

  • Since both pairs of opposite sides are parallel, ABCD is a parallelogram.

Similarity of Polygons

Two polygons are similar if their corresponding angles are congruent and their corresponding sides are proportional. The ratio of corresponding side lengths is called the scale factor.

Key Concepts

• Corresponding Angles: Angles in the same position in two different polygons.

• Corresponding Sides: Sides in the same position in two different polygons.

• Scale Factor: The ratio of any pair of corresponding side lengths in similar polygons.

Using Similarity to Solve Problems

1. Identifying Similar Polygons: Ensure that all corresponding angles are congruent and all corresponding sides are proportional.

2. Finding Missing Side Lengths: If you know two polygons are similar and you know the scale factor, you can find missing side lengths by setting up proportions.

   • (Side length of polygon A) / (Corresponding side length of polygon B) = scale factor

Example: Triangle ABC is similar to triangle XYZ. AB = 6, BC = 8, AC = 10, and XY = 9. Find YZ and XZ.

• Step 1: Find the scale factor.

  • Scale factor = XY / AB = 9 / 6 = 3/2

• Step 2: Set up proportions to find YZ and XZ.

  • YZ / BC = 3/2 => YZ / 8 = 3/2 => YZ = (3/2) * 8 = 12
  • XZ / AC = 3/2 => XZ / 10 = 3/2 => XZ = (3/2) * 10 = 15

• Step 3: Conclusion.

  • YZ = 12 and XZ = 15

Common Mistakes to Avoid

• Confusing Trapezoids and Parallelograms: Remember, a trapezoid has at least one pair of parallel sides, while a parallelogram has two pairs.
• Assuming Properties that Don't Exist: Be careful not to assume properties of a quadrilateral that aren't explicitly given or proven. For example, not all parallelograms are rectangles.
• Incorrectly Applying the Angle Sum Formulas: Double-check your calculations when using the interior and exterior angle sum formulas.
• Forgetting the Hierarchy: Keep the quadrilateral hierarchy in mind when classifying shapes. A square is always a rectangle, rhombus, and parallelogram.
• Misinterpreting Coordinate Geometry Formulas: Ensure you use the correct formula (distance, slope, or midpoint) and substitute values accurately.
• Mixing Up Corresponding Parts in Similar Polygons: Carefully identify corresponding angles and sides to set up correct proportions.

Frequently Asked Questions (FAQ)

• What is the difference between a convex and a concave polygon?

  • A convex polygon has all interior angles less than 180°, while a concave polygon has at least one interior angle greater than 180°.

• How do I find the number of sides of a regular polygon if I know the measure of one interior angle?

  • Use the formula: [(n - 2) * 180°] / n = (measure of one interior angle). Solve for n.

• What properties do all parallelograms have in common?

  • Opposite sides are parallel and congruent, opposite angles are congruent, consecutive angles are supplementary, and diagonals bisect each other.

• Is a square always a rhombus?

  • Yes, a square is always a rhombus because it has four congruent sides.

• How can I prove that a quadrilateral is a rectangle using coordinate geometry?

  • Prove that it is a parallelogram and that its diagonals are congruent OR prove that it is a parallelogram and that two adjacent sides are perpendicular.

• What is the relationship between the diagonals of a rhombus?

  • The diagonals of a rhombus are perpendicular bisectors of each other.

• How do you determine if two polygons are similar?

  • Two polygons are similar if their corresponding angles are congruent and their corresponding sides are proportional.

Conclusion

Mastering the properties of polygons and quadrilaterals is crucial for success in geometry. By understanding the definitions, theorems, and relationships discussed in this study guide, you'll be well-prepared to tackle your Unit 7 test. Remember to practice applying these concepts to various problems, and don't hesitate to review any areas where you feel uncertain. Good luck!
